輸出 解析度

VESA 解析度

格式/更新頻率

VGA (640x480)

RGBHV 50, 60, 72, 75, 85Hz

SVGA (800x600)

RGBHV 50, 60, 72, 75, 85Hz

XGA (1024x768)

RGBHV 50, 60, 72, 75, 85Hz

WXGA (1280x768)

RGBHV 50, 60Hz

SXGA (1280x1024)

RGBHV 50, 60Hz

480p (852x480)

YPbPr 50, 60Hz

576p (852x576)

YPbPr 50, 60Hz

720p (1280x720)

YPbPr 50, 60Hz

1080i (1920x1080)

YPbPr 50, 60Hz (note 1)

輸出格式

1T-TG-PCHD

類比式(Analog): RGBHV, YPbPr via HD15

1T-TG-DVI

DVI: RGBHV, YPbPr via DVI-I

外觀

Size (H-W-D)

1"x7"x4" (25x175x 100mm)

重量 (Net)

1.5lb ( 680g)

保固

保固期

2 Years Parts and Labor

環境設定

操作溫度
( Operating Temperature)

+32° to +120° F (0° to +48° C)

操作溼度
(Operating Humidity)

10% to 85%, Non-condensing

儲藏溫度
(Storage Temperature)

-40° to +150° F (-40° to +65° C)

儲藏溼度
(Storage Humidity)

10% to 85%, Non-condensing

電源需求

外掛電源供應器

12VDC @ 500mA Maximum

測試圖案

Color Bars

Color Bars/Multi-Burst (2)

Grayscale Steps - Light>Dark

Multi-Burst (Note 2)

Grayscale Steps - Dark>Light

Checkerboard

Fade - Black to White

White Field

Cross Hatch - Standard

Yellow Field

Cross Hatch - Small

Cyan Field

Chinese Characters 1

Green Field

Chinese Characters 2

Magenta Field

Chinese Characters 3

Red Field

Alternating 1 Pixel B/W Lines

Blue Field

Alternating 2 Pixel B/W Lines

Black Field

Alternating 3 Pixel B/W Lines

H Pattern

Alternating 4 Pixel B/W Lines

E Pattern

Large Circle

Circles - Repeating

國際認證

機器

FCC, CE

電源供應器

UL, CE, CSA

配件

1x AC Power Adapter

115VAC to 12VDC @ 800mA

Optionally Available

220VAC to 12VDC @ 800mA

註明

(1) The 1080i is actually a doubled 540p signal, which is recognized as a 1080i by most HDTV Displays.

(2) Not a true Multi-Burst. Alternating B/W Vertical Lines.
